Availability: In Stock
CAPTIVE-AIRE Low Profile Grease Rated Food Truck Exhaust Fan- High Speed Direct Drive Centrifugal Upblast Exhaust Fan with speed control- 19"-24.75" Fan Base, 115 Volt Single Phase Motor, (DU85HFA-)
Product Code: B0BP8D34Z3
$1.00

Available Options

Ask About This Product
Brand CAPTIVE-AIRE
Color Aluminum
Power Source Corded Electric
Style Custom
Product Dimensions 25"D x 25"W x 25"H
Voltage 115 Volts
Item Weight 62 Pounds
Model Name Low Profile
Control Method App
See more

About this item

  • Low Profile High Speed Direct Drive Centrifugal Upblast Exhaust Fan with speed control, disconnect switch and 15-3/4" wheel.
  • 24 3/4" x 24 3/4" Fan Base Dimension/ 109 LBs/ 1500-2200 CFM/ 0.75 HP 115 volt Single Phase Motor.
  • Rated for restaurant grease and general ventilation applications. UL705, UL762, & ULC-S645. Included with the exhaust fan is a mounting bracket specific for food trucks, concession trailers, and wall mount applications.
  • Construction features include a heavy gauge aluminum housing, a backward inclined, non-overloading wheel, a safety disconnect switch, a variable speed control, vibration isolators, and quick release latches for motor compartment access.
  • As all fans are custom built, no returns or exchanges are accepted.

Product Description

Low Profile High Speed Direct Drive Centrifugal Upblast Exhaust Fan with speed control, disconnect switch and 15-" wheel. 24 3/4" x 24 3/4" Fan Base Dimension/ 109 LBs/ 1500-2200 CFM/ 0.75 HP 115 volt Single Phase Motor. Rated for restaurant grease and general ventilation applications. UL705, UL762, & ULC-S645. Included with the exhaust fan is a mounting bracket specific for food trucks, concession trailers, and wall mount applications. Construction features include a heavy gauge aluminum housing, a backward inclined, non-overloading wheel, a safety disconnect switch, a variable speed control, vibration isolators, and quick release latches for motor compartment access.

Product information

Categories: Captiveaire Systems
Default
Brand CAPTIVE-AIRE
Color Aluminum
Control Method App
Item Weight 62 Pounds
Model Name Low Profile
Power Source Corded Electric
Product Dimensions 25in D x 25in W x 25in H
Recommended Uses For Product Exhausting
Style Custom
Voltage 115 Volts
Categories: Captiveaire Systems
